TECHNOMOTEUR S.A

Inverter Sol-Ark - 5K-2P / 48VDC/ 120/240VAC / Hybrid Inverter / Non stackable

Name: Inverter Sol-Ark - 5K-2P / 48VDC/ 120/240VAC / Hybrid Inverter / Non stackable
Brand: TECHNOMOTEUR S.A
SKU: SA-5K-2P-N
Availability: InStock

$0.00

Promotion Épuisé

Quantité

SPECIFICATIONS

GENERAL INFORMATION:

Manufacturer	Sol-Ark
Model Number	5K-2P
Certifications	UL1741 – 2010/2018, IEEE 1547a – 2003/2014, FCC 15 Class B, UL1741SA, CA Rule 21, HECO Rule 14H

MECHANICAL SPECIFICATIONS:

Dimensions	30.0” x 18.3” x 10.0”
Weight	78 lbs

ELECTRICAL SPECIFICATIONS:

Nominal AC Output	5,000 Watts
Max Output Current to the Grid	20.8 Amps
Max Output Current as Back-up	20.8 Amps
Battery Input Voltage	Nominal 48 Volts
Max Efficiency	97.5%
Max PV Power at STC	6,500 Watts
Max DC Voltage	500 Volts @ 18 Amps, 450 Volts @ 20 Amps
Start Voltage	125
MPPT Operating Voltage	150 - 425 Volts
Max Short Circuit Current per MPPT	2 Strings
Max Operating Current per MPPT	10 Amps (Self Limiting)

Solar Input Power
Max Allowed PV Power	3250 + 3250 = 6500W
Max PV Power Delivered to Battery & AC Outputs	5000W
Max DC Voltage (V_oc)	500V @ 18A, 450V @ 20A
MPPT Voltage Range	150-425V
Starting Voltage	125V
Number of MPPT	2
Max Solar Strings Per MPPT	2
Max DC Current per MPPT (Self Limiting)	10A
Max AC Coupled Input (Micro / String Inverters)	9600W
